BoltHold SP10-38 Asphalt Anchor, 6-PACK
6" long, 3/8" female thread, with bolt & washer, 1,500 lbs. pull rated
SP10-38K is a set of six steel asphalt anchors rated at 1,500 lbs. pull. The 6" long 5/8" diameter anchors are designed to anchor bike racks, plates, fences, and outdoor furniture directly to asphalt surfaces. The anchor performs well in 2.5" shallow asphalt which is common in parking lots and walkways in the US.
We offer 2 variants - Zinc plated for normal usage, and Stainless Steel anchors for applications near potable water or high salt environment.
Both variants incorporates a 3/8"-16 UNC female thread. The anchor requires a 7/8" hole 6" deep and the use of a grout such as our EPX2 or EPX3. A 1.4" head at the top of the anchor prevents the anchor from dropping below the surface. The SP10 anchors are mounted flush with the surface of the roadway, so that attached devices can be removed without leaving dangerous screws or protrusions on the walkway.
STAINLESS KIT: The SP10-3SK is a set of 6 anchors, each pre-installed with a 3/8" x 1" SS bolt and 1" diameter SS washer.
Technical Details
| Weight | 2.7 lbs |
|---|---|
| SKU | 01-6310.38K |
| Barcode | 0689481982502 |
| 3D Model | View 3D Model |
